Mitsubishi EVO IV-VIII Link juhtaju

Kirjeldus

Lihtne paigaldada. Taskukohane. Usaldusväärne.

G4X PlugIn ECU-d pakuvad mootori juhtimise uusimat tehnoloogiat, mis on loodud teie auto potentsiaali hõlpsaks maksimeerimiseks.
See ECU sobib tehase OEM-i korpusesse. Paigaldamine on imelihtne, alltoodud mudelite puhul ei ole vaja tehase juhtmestikku muuta.

See ECU on mõeldud EVO 4-8 4G63 mootorile.

• Enne ostmist kontrollige, kas teie pistik vastab loetletud fotol olevale päisele.
• See ECU töötab ainult manuaalkäigukastiga.
• Sisaldab pardal 4- või 7-baarilist MAP-andurit
• Enamik tehase funktsioone on toetatud.
• Kontrollige funktsioonide vahekaarti, et näha I/O laiendussuvandeid

Sobivad rakendused:

• CN9A Lancer Evolution 4
• CP9A Lancer Evolution 5, 6 ja 6.5 (TME)
• CT9A Lancer Evolution 7
• CT9A Lancer Evolution 8 (ainult 4-pistikuga ECU-ga mudelid)
• *Mõnel EVO 8-l on 3 pistikuga ECU. Need rakendused vajavad EVO9X Link ECU-d

PAIGALDUSJUHEND: EVOX8.pdf

G4X PlugIn Key Features (where applicable):

• Up to 6D fuel and ignition mapping
• Precision closed loop cam control (four cam, independent control)
• Sequential fuel delivery
• Digital triggering, all OEM patterns
• OEM idle hardware supported
• 5D boost control with three switchable tables
• Motorsport features – antilag, launch, flat shift
• Continuous barometric correction (on board)
• CAN port
• QuickTune – automated fuel tuning
• Individual cylinder correction
• USB tuning cable included
• Stats recording into on-board memory
• Gear compensations for spark, boost and fuel
• Real time selectable dual fuel, ignition and boost maps
• Sync and crank sensors can be a combination of Hall effect, variable reluctance or optical
• Boost control referenced to gear, speed or throttle position
• 512 mega bytes data logging memory
• Staged injection
• Knock with “windowing”

I/O Expansion Options

The following expansion connector inputs/outputs are provided:
The Mitsubishi Lancer Evolution IV – VIII plug-in ECU has two expansion connectors.

Expansion connector 1:

• Gnd                Sensor Ground Only
• +5V Out        Low Current +5V Supply
• DI 7                Digital input
• DI 8                Digital input
• DI 9                Digital input
• Aux 4                Auxiliary Output
• Ign 7                Ignition 7 Auxiliary Output
• Ign 8                Ignition 8 Auxiliary Output

Expansion Connector 2

• Gnd                Sensor Ground Only
• +5V Out        Low Current +5V Supply
• Aux 9                EThrottle – can’t be used as an Aux Out
• Aux 10                Auxiliary Output
• An Volt 6        Analog 0-5V input
• An Volt 7        Analog 0-5V input
• An Volt 9        Analog 0-5V input
• An Volt 10        Analog 0-5V input
